The automatic heavy machine is generally composed of a control device, a metering and detection machine, an automatic detection machine and a sorting crossing. The function of the control device is to recognize, receive and process the sorting signal, and according to the requirements of the sorting signal, the measurement and detection machine is instructed to automatically classify the goods by the type of goods, by the place of delivery of the goods or by the class of the cargo owner. These sorting needs can be entered into the sorting control system in different ways, such as through barcode scanning, color code scanning, keyboard input, weight detection, voice recognition, height detection and shape recognition, etc., according to the judgment of these sorting signals, to determine which sorting crossing a certain product should enter.
020-34563445Online checkweighing has gradually become an indispensable link in modern industrial production, especially in the production process of food and pharmaceutical industries. Automatic inspection machine in the product conveying process on the completion of the measurement of the product measurement, and measurement of measurement and pre-set range comparison, by the control box to send out instructions, the measurement of unqualified products will be rejected, or different measurement of the range of products sent to the designated area. Usually consists of a conveyor, detection mechanism, weighing mechanism. Among them, the weighing mechanism completes the collection of measurement signals, and sends the measurement signals to the control box for processing. The conveyor is mainly used to increase the speed to ensure that there is enough distance between the products. The weighing and inspection organization is used to reject the unqualified products after inspection.
It can be integrated with all kinds of packaging production lines and conveying systems, and is mainly used for on-line detection of whether the weight of products is qualified or not, and whether there are missing parts in the package. Or according to the different weight of the items to be conveyed to the corresponding weight range area. Generally consists of control device, measuring and testing machine, automatic testing machine and sorting channel. The role of the control device is to identify, receive and process the sorting signal, according to the requirements of the sorting signal to instruct the measurement and detection machine, according to the commodity species, according to the commodity delivery location or according to the owner of the category of goods for automatic classification. These sorting requirements can be through different ways, such as bar code scanning, color code scanning, keyboard input, weight detection, voice recognition, height detection and shape recognition, etc., input to the sorting control system, according to the sorting signals to determine the sorting signal, to decide a commodity to enter which sorting channel.
Technical Parameters
Sorting range: 10~1200g
Sorting precision: 0.5g
Sorting speed: Max.60 times/min, Max.120 times/min
Minimum display: 0.5g Sorting object (width 20~220mm) (length 50~400mm, 50~300mm) (height 12~42mm can be arbitrary)
Power supply: AC110/220V, 50/60HZ
Use of air pressure: 5kgf/c ㎡
