Weighing filling machine is a weighing filling, filling control, discharge and other computerized production process control and data management as one of the integrated automated filling control system, liquid filling machine using Mitsubishi Q series PLC and Advantech industrial control microcomputer to set up a high-performance control platform.
020-34563445Automatic Filling machine for viscous paste can be added hopper feeding, manual and automatic switching function, when the machine is in the "automatic" state, the machine according to the set speed, automatic continuous filling. When the machine is in the "manual" state, the operator steps on the pedal to realize the filling, if it has been stepped on and not let go, it will also become automatic continuous filling state. Anti-drip Filling system, filling cylinder up and down action, drive the filling head corresponding control.
Weighing filling machine is a weighing and feeding, filling control, discharge and other computerized production process control and data management as one of the integrated automated filling control system, Liquid filling machine using Mitsubishi Q series PLC and Advantech industrial control microcomputer to set up a high-performance control platform. The filling system adopts three-stage speed feeding mode, PLC controls the frequency converter through different combinations of output switching quantity for frequency conversion speed regulation, and the filling machine realizes fast feeding, slow feeding and fine feeding. At the beginning of weighing fast feeding, when the fast feeding prediction value W1 is reached, the slow feeding starts; when the slow feeding prediction value W2 is reached, the fine feeding starts; when the total weight of the feeding reaches the "target weight - pipeline weight a permissible error" when the filling stops, where the pipeline weight is the weight of the material remaining in the pipeline that will continue to flow into the filling barrel after the motor stops rotating, W1W2 is the percentage of the target weight, which is determined by the actual filling in the percentage of the target weight, W1W2 is the percentage of the target weight. W1W2 is the percentage of the target weight, the optimum value is taken from the actual filling, and the target weight and allowable error are set by the touch panel.
Basic parameters
Maximum weighing capacity: 30kg
Minimum Sensitivity: 5g
Filling range: 10-30kg
Filling precision: ≤0.1%
Filling speed: 200-500 cans/hour
Container specification: ≤φ300×h350
Gun head material: SUS304/316
Power supply: AC220/50Hz
Using gas source: 0.5Mpa
